Flexible Rope Fence Panel For Cable Fence

Model No.︰

DecorRope

Brand Name︰

Candurs

Country of Origin︰

China

Unit Price︰

CNY ¥ 88 / pc

Minimum Order︰

1 pc

Share on:

Product Description

China AISI 316 Flexible DecorRope flexible rope fence panel for cable fence  Factory,customized SS cable mesh height and  length .OEM service, Quick delivery.0 complain.

DecorRope Mesh

Flexible DecorRope flexible rope fence panel for cable fence is assembed by seamless ferrules and stainless steel wie rope.Diamond mesh when it is stretched at 60° angle ( Option: 90° angle ).Read more ...

Ferrule : Each seamless ferrule offers high break loading capacity. Availabe AISI 316 stainless steel ferrule ( Optio : Tinned Copper Ferrule )

Wire  Rope : Available AISI 316 stainless steel cable (Option : AISI 304 ) ,high tensile strength,bright,wear and abrasion resistant.

Advantages

DecorRope flexible rope fence panel for cable fence has their characteristic property and capacity to replace other steel wire mesh in certain applicationa.Sometimes better.

  • Unique design idea.3D-structure,Flexible,elegant,discreet,filigreed,multifuncational.
  • Light weight,High open area % .
  • Corrosion resistant,allows strongh airflow.
  • Total pro-environment,recyclable,no toxic,non flammable,Maintenaance free,don't ask any special cleaning & coating.
  • At least 20 years guaranteed

Panel Shape

Supplied Square panel shape, Rectangular panel shape. Rhombus panel shape, Triangular panel shape, circle panel shape,and other art shape.Customized net height and length.

Easily Install

DecorRope flexible rope fence panel for cable fence is main installed on tube frame, perimeter cables or wire rod with special border design Available 30 type different border plans to meet different install required.

Wide Application

Façade screens, Railing mesh infill panel, Balustrade mesh infill panel. Balcony mesh infill panel, Bird netting, Security platform fence. Isolate fence, Garden fence, Zoo mesh, Animal enclosures net etc.

Easily Order :

1. Wire Diameter : Available AISI 304  and 316 ,Cable diameter: 1.0 mm (7*7 ), ,1.5 mm (7*7 ), 2.0 mm (7*7 )

3.0 mm (7*19)   ,4.0 mm (7*19)     DecorRope Mesh Structure





2. Opening :Available Opening width ( OW ) 20mm - 200mm. Opening Height ( OH ) 35mm - 346mm

Opening (mm)

OW X OH

Wire Diameter
1.0 mm 1.5 mm 2.0 mm 3.0 mm 4.0 mm
25 x 43 CD1025 CD1525
30 x 52 CD1030 CD1530
35 x 61 CD1035 CD1535
40 x 69 CD1040 CD1540 CD2040
50 x 87 CD1050 CD1550 CD2050 CD3050 CD4050
60 x 104 CD1060 CD1560 CD2060 CD3060 CD4060
70 x 121 CD1070 CD1570 CD2070 CD3070 CD4070
80 x 139 CD1080 CD1580 CD2080 CD3080 CD4080
100 x 173 CD10100 CD15100 CD20100 CD30100 CD40100
120 x 242 CD10120 CD15120 CD20120 CD30120 CD40120
160 x 277 CD10160 CD15160 CD20160 CD30160 CD40160
180 x 312 CD10180 CD15180 CD20180 CD30180 CD40180
200 x 346 CD10200 CD15200 CD20200 CD30200 CD40200

3.Opening Orientation:

DecorRope Mesh Opening Orientation

4. Border plans: Such as L10,L18,L22,L24 ...

5. Nets height and length,Quantity.

6. Inquiry : sales@candurs.com

----------------------

Candurs is a professional stainless steel wire rope mesh manufacturer in China.experienced in providing DecorRope and WovenRope stainless steel cable mesh for all kinds of decorative & architectural mesh screens and other necessary security application.Customizedmesh height and length.

  • OEM Service
  • 0% complain.
  • Quick delivery
  • Suggest suitable border plans for installation
  •


Product Image
